O70RL

Wireless radiator thermostat

•
•
•
•

O70RL FOR MORE INFO

•
•
•
•

• DESCRIPTION
• ADVANTAGES
• TECHNICAL SPECIFICATION
• HOMOLOGATION AND INSTALLATION
• TECHNICAL LITERATURE

• DESCRIPTION
  0

  The O70RL wireless radiator thermostat replaces the manual adjustment knob on the thermostatic valve of the radiator.
  The actuator controls the valve’s piston to modulate the water flow, maintaining the room temperature set on the programmable thermostat or on the radiator thermostat itself.

  General features

  • Connection: M30x1,5
  • Transmission frequency in ISM band EU868
  • RF power < +14dbm
  • Radio modulation: LoRa®
  • Firmware update via radio (OTA)
  • Temperature display: Celsius (°C)
  • Temperature regulation range: 2 ÷ 30 °C; increment 0.1 °C
  • Operating temperature: 0 ÷ 40 °C
  • Storage temperature: -20 ÷ 65 °C
  • Relative storage humidity: 20 ÷ 80% (90% without condensation)
  • Protection rating: IP30

  Electric features

  • Power supply: 2 AA 1.5V alkaline batteries
    (do not use rechargeable batteries)
  • Autonomy: up to 12 months (depending on usage mode)
• ADVANTAGES
  0

  The O70RL wireless radiator thermostat replaces the manual adjustment knob on the thermostatic valve of the radiator.
  The actuator controls the valve’s piston to modulate the water flow, maintaining the room temperature set on the programmable thermostat or on the radiator thermostat itself.

  Advantages

  • Universal installation
  • Display orientation in 3 positions
  • Open window detection function
  • Ability to lock settings
  • Stand-alone operation and possibility of integration into a Fantini Cosmi LoRa® multi-zone radio temperature control system
• TECHNICAL SPECIFICATION

  Code

  Connection

  Transmission frequency in ISM band

  RF power

  Radio modulation

  Firmware update

  Power supply

  Autonomy

  Temperature display

  Temperature regulation range

  Operating temperature

  Storage temperature

  Relative storage humidity

  Protection rating

  O70RL

  M30x1,5

  EU868

  < +14dbm

  LoRa®

  via radio (OTA)

  2 AA 1.5V alkaline batteries (do not use rechargeable batteries)

  up to 12 months (depending on usage mode)

  Celsius (°C)

  2 ÷ 30 °C; increment 0.1 °C

  0 ÷ 40 °C

  -20 ÷ 65 °C

  20 ÷ 80% (90% without condensation)

  IP30

• HOMOLOGATION AND INSTALLATION
  Homologation

  • Compliant with Directive 2014/30/UE (EMC);
  • Directive 2014/35/UE (LVD);
  • Directive 2014/53/EU (RED)

  Installation and use

  • The wireless radiator thermostat O70RL regulates the flow of hot water into the radiator based on the set ambient temperature.
  • O70RL can be installed on all thermostatic valves with an M30x1.5 connection; if necessary, for other types of valves, use the most suitable adapter (not included in the package).
  • To proceed with the installation of the wireless radiator thermostat on the radiator valve body, screw the head’s ring onto the valve’s threaded connection.
  • O70RL can be mounted both vertically and horizontally. Set the display orientation by rotating the knob until the ‘UP’ label is correctly positioned; confirm by pressing the knob.

  ---

  The O70RL wireless radiator thermostat allows to set the desired temperature in each zone or room, adapting to the user’s thermal comfort needs and enabling significant heating cost savings. The actuator acts on the valve piston, opening or closing the water flow to maintain the set ambient temperature. O70RL can be used both in stand-alone mode with local adjustment (where the user can view both the ambient and set temperatures on the valve) and integrated into a Fantini Cosmi LoRa® multizone radio temperature control system, with remote management.

  ACCESSORI

  • Code 309703A: Adapter for IRSAP/CALEFFI valves
  • Code 309704: Adapter for Giacomini valves
  • Code 309706A: Adapter for FAR valves
• TECHNICAL LITERATURE
  • O70RL technical data sheet
  • O70RL instructions
  • Brochure multi-zone termoregulation system
